50kg Heavy-Duty Integrated Palletizing Robots AM-50-Ultra
Collaborative Robot Features:
- Intelligent Collaboration: Works seamlessly with human operators for enhanced productivity.
Safe Design: Equipped with advanced sensors for collision avoidance ensuring worker safety.
Wide Range of Applications: Suitable for manufacturing, assembly, and logistics tasks.
Ergonomic Handling: Easy to operate with intuitive controls for improved efficiency.
Durable Construction: Built to withstand industrial environments with robust materials.
share:
As the top-tier heavy-load model of the product lineup, the AM-50 cobot palletizer series is designed for ultra-heavy carton palletizing applications, supporting a maximum payload of 50kg to handle the heaviest conventional packaging materials. Adhering to stable and durable industrial design, the series runs at a stable cycle speed of 7 cartons per minute, ensuring precise and safe completion of high-weight stacking tasks. It contains two core configurations: the AM-50-G with 1800mm working reach and 1900mm standard stacking height for conventional heavy-load production lines, and the AM-50 Ultra with 2100mm extended reach and 2100mm stacking height for larger operating range and higher stacking demands. The whole machine adopts an enhanced robust mechanical structure and optimized load-bearing design, with excellent anti-fatigue performance to adapt to long-term high-intensity industrial operation. With reliable human-machine collaboration safety protection, simple deployment and strong scene adaptability, the AM-50 series provides high-stability, high-efficiency automated palletizing solutions for heavy industry, large logistics warehouses and high-load packaging production lines.
| Parameter Item | AM-50-G | AM-50 Ultra |
|---|---|---|
| Payload | 50kg | 50kg |
| Reach | 1800mm | 2100mm |
| Pallet size | Compatible with pallet within the 1800mm working radius | Compatible with pallet within the 2100mm working radius |
| Palletizing height | 1900mm | 2100mm |
| Speed | ≤7pcs/min | ≤7pcs/min |
| Repeatability | ±0.04mm | ±0.04mm |
| Air consumption | 240-460L/min | 240-460L/min |
| Communication | EtherCAT, IO | EtherCAT, IO |
| IP rating | IP54 | IP54 |
| Temperature | 0-50℃ | 0-50℃ |
| Max power | 5kw | 5kw |
| Power supply | 220V/50Hz | 220V/50Hz |
| Weight | ≈370kg | ≈380kg |
| Footprint | 1973mm*1488mm | 1973mm*1488mm |
