A2-4-30 Machine Sync With Brake Spindle
Spindle Feature：
- Products in strict accordance with the import standard inspection, long life, good stability.
- Large through-hole to enhance the product processing range, can meet 30MM material
- Can meet the high speed, high light turning requirements
- Optional triangle belt, 88/8YU synchronization belt and other different structures
- The magnetic ring of various manufacturers can be selected, and the split brake pad is equipped
share:
| Product drawing number | A2-4-30 | Spindle name | 30 Machine sync with brake |
|---|---|---|---|
| speed of main shaft | 6000-8000RPM | Belt specification | 8M/8YU-36T |
| Assembly form | Horizontal type | Balance class | G1 |
| Spindle through hole | 40MM | Driving horsepower | 2.2-3.5Kw |
| Spindle specification | A2-4 | Front bearing arrangement | 7012 |
| lubricating system | Grease lubrication | Rear bearing arrangement | 7012 |
| Bore specification | MT#5 | ||
| Unit：MM | 1:3 | ||
| Drawing date | 2023.7.20 | ||
