90Degree BT40-FMB16 Special Side Milling Head For Disc Cutter

90Degree BT40-FMB16 Special Side Milling Head For Disc Cutter

   Milling Head Feature:
  • The shell is made of aviation aluminum,through aging treatment,precision machining,with high rigidity,high precision,long life and other characteristics.The minimum?pass allowed ¦µD30mm
  • The main drive shaft is made of special alloy material, processed by strict heat treatment process, and finally finely ground to achieve high transmission stability
  • Gear wheel bearings are imported to ensure the transmission of high torque, low noise.
  • Input and output forms are diverse and flexible, not limited to BT or ER interface.can meet all kinds of precision machining equipment, can be used for milling.drilling,tapping,grinding and other processes of processing
SKU: BT40-FMB16 Categories: , Brand:

share:

ITEM XM90-BT40-FMB16-66
Driving Shank BT40
More Shank Can Be Used
Max.rpm 4000RPM
Output Rotation CW-CW
Ratio Of Transmission 1:1
Through TheDiameter D30
Chucking Range FMB16
Tapping F66
Torque 46.Nm
WT 6.5kg
Inventory Stock
Custom Customization
